The MQW03 jet mill classifier injects compressed air at high speed through nozzles so that material is crushed by collision, friction and shear inside a rotating grinding chamber. The ground material is then separated into different particle-size fractions in a precision classifying zone. It features an accurate cut point, adjustable product fineness, a quick-open structure for easy cleaning, an intelligent control chip, and broad material compatibility.
150-5445-08687*24 hours hotline
Guide installation
Chauffeur pick-up
After-sales service
The MQW03 jet mill classifier injects compressed air at high speed through nozzles so that material is crushed by collision, friction and shear inside a rotating grinding chamber. The ground material is then separated into different particle-size fractions in a precision classifying zone. It features an accurate cut point, adjustable product fineness, a quick-open structure for easy cleaning, an intelligent control chip, and broad material compatibility.
| Parameter / Model | MQW03 | MQW06 | MQW10 | MQW20 |
| Feed size (mm) | <3 | <3 | <3 | <3 |
| Product size d97 (μm) | 2-45 | 2-45 | 2-45 | 2-45 |
| Capacity (kg/h) | 2-10 | 10-50 | 50-100 | 100-500 |
| Air consumption (m³/min) | 3 | 6 | 10 | 20 |
| Air pressure (MPa) | 0.7-0.85 | 0.7-0.85 | 0.7-0.85 | 0.7-0.85 |
| Installed power (kW) | 21.8 | 42.5 | 85 | 147 |
